起源の場所:
中国
ブランド名:
Cat DEO 424B
モデル番号:
猫 DEO 424B
| Category | Specification |
|---|---|
| Model | Cat 424B Skid Steer Loader |
| Power Unit | |
| - Engine Model | Cat C3.4B (Tier 4 Final / Stage IV compliant) |
| - Rated Power | 55 kW / 74 hp (Net Power) |
| Operating Specifications | |
| - Rated Operating Capacity (ROC) | 1,134 kg (2,500 lb) @ 50% of tipping load |
| - Operating Weight | Approx. 3,765 kg (8,300 lb) (with cab) |
| - Standard Bucket Capacity | 0.75 m³ (1.0 yd³) |
| - Tipping Load (Straight) | 2,270 kg (5,000 lb) |
| Performance | |
| - Travel Speed | Up to 11.8 km/h (7.3 mph) |
| - Lift Arm System | Vertical Path |
| - Breakout Force | 31 kN (7,000 lbf) (approx.) |
| - Hinge Pin Height | 2,997 mm (118 in) |
| - Dump Reach | 711 mm (28 in) (at hinge pin height) |
| - Ground Clearance | 229 mm (9 in) |
| Hydraulic System | |
| - Auxiliary Hydraulic Flow | High Flow optional |
| - Relief Valve Pressure | 24.1 MPa (3,500 psi) |
| Dimensions | |
| - Length (without bucket) | 3,480 mm (137 in) |
| - Width | 1,930 mm (76 in) |
| - Height (to top of ROPS) | 2,080 mm (82 in) |
| - Wheelbase | 1,220 mm (48 in) |
Why choose us:
Regular maintenance and inspections.
Troubleshooting and repair services.
Replacement parts and components.
Operator training and safety courses.
Video support and assistance.
contact us:
For more information about our technical support and service options, please contact us:
Tel: (86) 147629878128
Whats APP: 86 15298385190
Email: lisalucky2025@gmail.com
Packing and Shipping
Used excavators are packaged in a safe and protective manner to ensure transportation safety.
Based on the size and weight of the excavator, we use wooden boxes, steel frames, or pallets to package the product.
We use reputable transportation companies, and once the product is shipped, we will provide tracking information.
| Products 产品 | Brand 品牌 | Model |
| Used Excavator | CAT | 306,307,312D,315D,320C,320D,325,330D,336D,349D |
| Hitachi | EX60,EX70,EX75,EX120,EX200,EX240,EX270,EX300,EX350,EX450 | |
| ZX60,ZX70,ZX75,ZX120,ZX200,ZX270,ZX300,ZX350,ZX450 | ||
| Komatsu | PC35,PC55,PC60,PC70,PC120,PC130,PC200,PC220,PC300,PC350,PC360,PC400,PC450 | |
| Kobelco | SK60,SK75,SK120,SK200,SK260,SK350 | |
| Doosan | DH55,DH60,DH150,DH220,DH225,DH300 | |
| DX55,DX60,DX150,DX220,DX225,DX300 | ||
| Hyundai | 130,150,215,225,305 | |
| Volv-o | EC60,EC140,EC210,EC240,EC290,EC300,EC360,EC460,EC480 | |
| Kubota | U15,U17,U30,U35,KX155,KX165 | |
| SANY | 55,60,75,95,135,215,235 | |
| Used Bulldozer | CAT | D3(C/G/H),D4(C/H),D5(K/M),D6(G/H),D7G,D8R,D9R |
| Komatsu | D31EX,D65E,D85,D155,D275,D375,D65PX | |
| Shangong | SEM816,SEM818 | |
| Shantui | SD13,SD16,SD22,SD32 | |
| Used Loader | CAT | 938G,966F,966H,966G,950GC,980G |
| Komatsu | WA320,WA380,WA470,WA500,WA600 | |
| XCMG | 50GN | |
| LIiugong | LG856,856H,835,836,862 | |
| Shangong | SEM650,652 | |
| Lingong | LG936,956,958,968 | |
| Used Backhoe Loader | JCB | 3CX,4CX, |
| CASE | 508M,580L,580N | |
| Lingong | 776,777 | |
| Used Motor Grader | CAT | 12G,4G,120G,140G,140K |
| Komatsu | GD511A,GD655 | |
| XCMG | GR180,GR215 | |
| LIiugong | 61,416,141,804,215 | |
| Shangong | 919,921 | |
| Lingong | 9180 | |
| Used Road roller | SANY | STR140,STR160,SSR220A,SSR200A |
| XCMG | CA25/30,XS143/163/183,XS203/223/263 | |
| Liugong | LG614,616,618,620,622,626 | |
| Shantui | SR16,SR18,SR20,SR22 |
